article number
▲ new (old) ▼ | ▲ article description: ▼ |
|
| #01 | | 100703
(08903006) | | DAN flap lock
with slotted holes - galvanised - | | |  | | ▶ details |
|
|
| #02 | | 100699
(05901100) | | Motor Actuator CC
AP-150/M V24 C200 S16 M2+D F00 | | |  | | ▶ details |
|
|
| #03 | | 103500
(01907400) | | Lid over filler opening for SPB AN
one-piece, complete with accessories / standard angled | L= 155 cm | B= 159 cm
H= 5 cm |
(Zgnr. SDA00214556) | |
 8 | | ▶ details |
|
|
| #04 | | 105716
(01907465) | | Bracket for opening bar left | L= 33 cm | B= 18 cm
H= 8 cm | 1 Kg
(Zgnr. SZ00218388) | |
1 | | ▶ details |
|
|
| #05 | | 104398
(01907463) | | Bracket for opening bar right | L= 33 cm | B= 18 cm
H= 8 cm | 1 Kg
(Zgnr. SZ00218389) | |
2 | | ▶ details |
|
|
| #06 | | 107360 | | Closure flap for DAN closure
For welding to the centre-split cover | 0.2 Kg
(Zgnr. SU00010310) | | | | ▶ details |
|
|
| #07 | | 100888
(40010100) | | Container brush 150cm, 181510 | | | | | ▶ details |
|
|
| #08 | | 104397
(01907930) | | Cover storage
for centre-split lids | | | | | ▶ details |
|
|
| #09 | | 107587 | | Cylinder holder for hydraulic cover
incl. bolt, 2 washers A 23 and split pin 5 x 36 | L= 10.8 cm | B= 5.3 cm
H= 4.9 cm | 0.9 Kg
(Zgnr. SZ00098764) | | | | ▶ details |
|
|
| #10 | | 107974
(01906015) | | Edge protection with hose
0 150 -soft, 25 mtr. roll | | | | | ▶ details |
|
|
| #11 | | 109234 | | Fixed tab
75 x 38 x 10 mm | | | | | ▶ details |
|
|
| #12 | | 106969 | | Folding lid over filler opening for SPB SEL
complete with accessories |
(Zgnr. SU00305468) | | | | ▶ details |
|
|
| #13 | | 108339
(01907473) | | Hinge for SPB hydraulic cover | | | | | ▶ details |
|
|
| #14 | | 105779
(01907417) | | Holder for opening ropes, riveted | | | | | ▶ details |
|
|
| #15 | | 108494 | | Intervention guard SPB AN-E in PR left | L= 55 cm | B= 29.5 cm
H= 14.8 cm | 3.9 Kg | | | | ▶ details |
|
|
| #16 | | 108495
(01907484) | | Intervention guard SPB AN-E in PR right | L= 55 cm | B= 29.5 cm
H= 14.8 cm | 3.9 Kg | | | | ▶ details |
|
|
| #17 | | 108779 | | Intervention protection
3 x 347 x 900 mm | | | | | ▶ details |
|
|
| #18 | | 107265
(01907485) | | Intervention protection, legal | 4.6 Kg | | | | ▶ details |
|
|
| #19 | | 108419 | | Intervention protection, links | | | | | ▶ details |
|
|
| #20 | | 105717
(01907903) | | Lid bearing with retaining shoe Centre split lid
in pressing direction lefft | L= 57 cm | B= 5 cm
H= 10.5 cm | 2.5 Kg | |
1 | | ▶ details |
|
|
| #21 | | 1 Stück
105718
(01907902) | | Lid bearing with retaining shoe Centre split lid
in pressing direction right | L= 57 cm | B= 5 cm
H= 10.5 cm | 2.5 Kg | |
1 | | ▶ details |
|
|
| #22 | | 103523
(01907430) | | Lid over filler opening for SPB AN
two-piece, complete with accessories / standard angled | L= 137 cm | B= 159 cm
H= 5 cm |
(Zgnr. SDA00228954) | |
12 | | ▶ details |
|
|
| #23 | | 103514
(01907406) | | Lid over filler opening for SPB SEL
one-piece, complete with accessories / standard angled | L= 221 cm | B= 197 cm
H= 5 cm |
(Zgnr. SU00212867) | |
17 | | ▶ details |
|
|
| #24 | | 109731 | | Lid over filler opening for SPB SEL
one-piece, on straight sides | 90.5 Kg
(Zgnr. SU00217267) | | | | ▶ details |
|
|
| #25 | | 103527
(01907436) | | Lid over filler opening for SPB SEL
two-piece, complete with accessories / standard angled | L= 220 cm | B= 195 cm
H= 5 cm |
(Zgnr. SU00217614) | |
12 | | ▶ details |
|
|
| #26 | | 103512
(01907404) | | Lid over filler opening for SPB SEN
one-piece, complete with accessories / Standard sloping | L= 182 cm | B= 197 cm
H= 5 cm | 90 Kg
(Zgnr. SV00214551) | |
10 | | ▶ details |
|
|
| #27 | | 103526
(01907434) | | Lid over filler opening for SPB SEN
two-piece, complete with accessories / standard angled | L= 178 cm | B= 195 cm
H= 5 cm |
(Zgnr. SV00217835) | |
12 | | ▶ details |
|
|
| #28 | | 103507
(01907403) | | Lid over filler opening for SPB SW
one-piece, complete with accessories / standard angled | L= 138 cm | B= 176 cm
H= 5 cm | 90 Kg
(Zgnr. SDW00214567) | |
6 | | ▶ details |
|
|
| #29 | | 103502
(01907401) | | Lid over filler opening for SPB SW-AN
one-piece, complete with accessories / standard angled | L= 148 cm | B= 130 cm
H= 5 cm |
(Zgnr. SD00260527) | |
6 | | ▶ details |
|
|
| #30 | | 107533 | | Offset automatic cover SPB SW
one-piece, can be raised at the front | L= 149.8 cm | B= 183.8 cm
H= 30 cm | 58 Kg
(Zgnr. SD00250310) | | | | ▶ details |
|
|
| #31 | | 104400
(01907920) | | Opening lever straight
27 x 3 x 600 mm | L= 60 cm | B= 3 cm
H= 3 cm | 1 Kg | | | | ▶ details |
|
|
| #32 | | 108423 | | Retaining arm for one-piece lid | L= 49.4 cm | B= 23.1 cm
H= 1.0 cm |
(Zgnr. SZ00097698) | | | | ▶ details |
|
|
| #33 | | 100617
(01907450) | | Rubber buffer diameter 50 x 17
M 10 crowned | 0.7 Kg | | | | ▶ details |
|
|
| #34 | | 100618
(01907451) | | Rubber-metal buffer
Version D, 18 x 7,5 / M6 x 16 |
(Zgnr. KKA00136907) | | | | ▶ details |
|
|
| #35 | | 103906 | | Safety bar
for new center split cover SEL / SEN | L= 4 cm | B= 3 cm
H= 196 cm | | | | | ▶ details |
|
|
| #36 | | 108491
(01907042) | | Safety bar SPB AN
for center split cover SPB AN | L= 4 cm | B= 3 cm
H= 156.5 cm | | | | | ▶ details |
|
|
| #37 | | 109089 | | SK nuts DIN 6330-10 black B M10 | | | | | ▶ details |
|
|
| #38 | | 109803 | | SPB SEL centre cover |
(Zgnr. SU00171710) | | | | ▶ details |
|
|
| #39 | | 100840
(25250075) | | Spring bolt with grease nipple
M + H # 8342, opening bar lock | L= 5 cm | B= 3 cm
H= 3 cm | 0.1 Kg
(Zgnr. SV00083371) | | | | ▶ details |
|
|
| #40 | | 100698 | | Stopper with slats 60 x 40 x 2mm | L= 6 cm | B= 4 cm
H= 0.2 cm | | | | | ▶ details |
|
|
| #41 | | 103625
(01907419) | | Strap SEN / SEL with riveted metal straps
Length 3570 mm | L= 375.0 cm |
(Zgnr. SZ00169217) | |
2 | | ▶ details |
|
|
| #42 | | 103624
(01907418) | | Strap SW / AN with riveted metal straps
Length 2450 mm | L= 245.0 cm |
(Zgnr. SZ00195786) | |
2 | | ▶ details |
|
|
| #43 | | 104317
(01907472) | | Top bearing SPB 20.5mm bore | L= 8 cm | B= 3 cm
H= 5 cm |
(Zgnr. SZ00208372) | | | | ▶ details |
|
|
| #44 | | 107226
(01907423) | | Webbing, 25 mm, red | | | | | ▶ details |
|
|
| #45 | | 107053 | | Weld-on triangle for cover
Rubber seal, 30 x 30 mm |
(Zgnr. SZ00169422) | | | | ▶ details |
|
article number new
(article number old) |
Husmann Spare parts catalogue
